Lonsdor K518 Program a Key and Remote for 2017 KIA Ceed: Done!

2017 KIA Ceed key and remote control programming… Lonsdor K518ISE work well!

80 bit immo system-pin code reading is not possible, do not read!

Got key by dump. you can key in pin code reading!

Only MK programmer knows! Abrites, Tango, Lonsdor I couldn’t read.

londor-k518-kia-add-key-1 londor-k518-kia-add-key-2

Then in Lonsdor:

Immobilizer – KIA – Select from vehicle – General area – Cee’d (JD) – 2013 – 2016
londor-k518-kia-add-key-3 londor-k518-kia-add-key-4

Two key fobs ready for programming


Insert key and switch ignition on


Enter pin codes


Programming completed

Will program the next one


Replace another new key and switch ignition on



Programming completed!


Pls remove the key and wait for 5s

Programming completed!


Test the new key on the car

It starts




Lonsdor has a big success!

Big thank ?to Slavo Backov? for his contribution

Upgrade Process for K518 Adaptor Kernel

After the APK of Lonsdor K518S Key Programmer is upgraded to V1.6.0 version, the adaptor requires to be installed new kernel beforehand. Please refer to below operations.

Step 1: Connect the device to the specified adaptor and plug in 12V power, as shown below.


Step 2 : Start up the device, and input password to enter home screen. Click “Update firmware” button in below red box.


Step 3: The following interface appears, click “Install Adaptor” in below red box.


Step 4: It skips to the below interface, click “OK” to continue.


Step 5: It skips to below interface. You will see the progress indicator moving rightwards. When downloading is completed, click OK” and exit. The adaptor kernel is installed successfully.


Porsche-Cayenne-Help File

Basically, there will be 4 parts in the whole help file: Function, Reference, Attention and Operation.


1. Program smart key: to program smart card (please make dealer key first);

2. Make dealer key: use the backed up BIN data to make the non-dedicated key to be dealer key.


Chip type: Dedicated smart card

Frequency: 315/433/434 frequency (please check the logo in the lower right of the lid of the BCM box)

Key embryo no.: 31

Code requirement:Dismantle & read BCM to make dealer key

Key generation: Program smart key complete, remote will automatically generated

Under the steering wheel (BCM position):

Porsche-Cayenne-Help- File-1
BCM is located at the bottom left of the steering wheel, please note the frequency type, basically there will be 315/433/434,

The following picture is for 434 frequency:
Porsche-Cayenne-Help- File-2

11-15 Cayenne Car Model

Porsche-Cayenne-Help- File-3

The car key

Porsche-Cayenne-Help- File-4

The induction keyhole

Porsche-Cayenne-Help- File-5

The mechanical knob key inserted into the induction keyhole

Porsche-Cayenne-Help- File-6


1. All the keys need to learn, or it will not be able to start the vehicle, it is recommended to learn the original car keys first,and then learn the new key, battery must be well installed.

2. The newly added key must be either the dealer key made via the car BCM data, or the key ordered back through the VIN code.

3. When learning key, it is required to insert the key into the induction keyhole, to learn a smart key, remove the machanical rotate key from the induction keyhole if any and then insert the smart key to program.


Step 1: Use the Lonsdor K518S to read and write BCM data and save it as bin file;

1. BCM is located in the lower left of the steering wheel, please pay attention to view the frequency type, usually there will be 315,433,434 frequency (below picture is for 434):

Porsche-Cayenne-Help- File-7

2. Read the BIN (D-FLASH / EEPROM) file with the programmer specifically for reading BCM. Please pay attention to the type here: namely 1L15Y 2M25J metal crystal, or 5M48H 1N35H ceramic crystal (red mark):

Porsche-Cayenne-Help- File-8

3. Please refer to the following picture to wire:
Porsche-Cayenne-Help- File-9

Porsche-Cayenne-Help- File-10

Step 2: Copy the bin file into Auto key Programmer K518ISE: please use the USB cable to connect the K518ISE to the computer, open the device internal memory, find the folder “customfile” and copy the bin file into it (as shows below).

Note: bin file suffix “bin” must be lower case letters, directly put the file into the folder rather than create a new folder:
Porsche-Cayenne-Help- File-11

Step 3: Make dealer key

Step 4: Program smart key

Lonsdor K518 reads PIN for older Fiat 2005-2012: Confirmed!

Question for Lonsdor K518S:

When You are planning to add PIN read for older Fiat ??

(Doblo 2005 – 2009 or Ducato 2006 – 2012 etc. )

Answer by CnAutotool.com:


The steps:

Read dump with FVDI

Then VVDI-Prog can calculate PIN from dump

(Tango doesn’t show pin, and you need pin for remote programming)

Then continue with Lonsdor – Immo learn + remote

The test on Doblo:


Select a model:

Fiat- Europe-Doblo-2009-
lonsdor-k518ise-older-fiat-read-pin-2 lonsdor-k518ise-older-fiat-read-pin-3 lonsdor-k518ise-older-fiat-read-pin-4 lonsdor-k518ise-older-fiat-read-pin-5

Lonsdor reads PIN codes


The function can read PIN code and save data


Pls use a working key to turn ignition ON

For a smart key, pls put it close to induction coil


Open the ignition switch


K518 manages to read PIN codes

PIN is saved

Pls use [program key] function to program a key


Lonsdor K518 Newest Update Espace/Megane 4/Scenic 4

Lonsdor K518ISE Newest Update On April.27,2019:

Espace(2015-):Make dealer key/Program smart key and mechanical key
Megane 4(2015-):Make dealer key/Program smart key and mechanical key
Scenic 4(2015-):Make dealer key/Program smart key and mechanical key


Lonsdor K518ISE adds VW Skoda Audi Models (2019-04-10)

Lonsdor K518ISE Key Programmer released new free software update on April 10th, 2019.

Software Update:
Identification function: add more identification types for VW, Skoda, Audi

Software optimization:
Jetta Bora (2014-): repair menu for NEC24C64/95320 IMMO


Program Toyota Corolla 2012 72G Remote Key with Lonsdor K518ISE

The task is to make 2 new master keys after lost all keys on a 2012 Toyota Corolla car with key chip 72G. Immobilizer reset, key programming and remote control programming is done with Lonsdor K518ISE Key Programmer.

Main steps:

Step 1: Generate 72G key chip

Step 2: Reset IMMO

Step 3: Program 1st master key

Step 4: Add another master key

Step 5: Program remote control

Step-by-step procedure:

Step 1: Generate 72G key chip

lonsdor-k518-2012-toyota-corolla-2 lonsdor-k518-2012-toyota-corolla-3 lonsdor-k518-2012-toyota-corolla-4

In Lonsdor K518ISE, select Generate key chip->4D->Toyota 72G

Place a blank chip into K518 card slot, press OK


Select a master key position



Generate 72G key chip succeed.

Step 2: Reset IMMO

Select Immobilizer->Toyota-> Select from vehicle->China->Corolla->2012 up-> Mechanical key (with 72 G)->Reset Immobilizer (all key lost)

lonsdor-k518-2012-toyota-corolla-8 lonsdor-k518-2012-toyota-corolla-9 lonsdor-k518-2012-toyota-corolla-10

Turn off ignition switch

Switch ignition ON

Getting immo data


Switch ignition off and remove key

Turn on ignition again


Programming key in progress


Switch ignition off and remove key

Step 3: Program 1st master key

Follow steps below to program key within 120s (here we need to program 1 master key)

lonsdor-k518-2012-toyota-corolla-16 lonsdor-k518-2012-toyota-corolla-17

Program 1 master key:
Insert the first master key, switch ignition on and wait 5 sec, and then switch ignition off 5 times. When immo indicator goes off, programming completed.


1st master key programming completed

The key can start car.

Step 4: Add another master key

Select Add key function
A master key is required before remove or add other keys.


Insert the programmed original key into ignition


Insert the key to be programmed. Don’t turn on the ignition switch.


Wait for the security light go off. Programming completed.

Step 5: Program remote control

In Lonsdor K518, go to Immobilizer->Toyota->Select from vehicle->China->Corolla->2012 up->Remote->Program remote

lonsdor-k518-2012-toyota-corolla-25 lonsdor-k518-2012-toyota-corolla-26
Turn on ignition switch

Open the driver door. When the internal locks is open, open other doors.

Reading data

Press and hold the lock and unlock buttons of the remote to be programmed for 2 sec simultaneously within 30 sec, press the lock button once, click OK to continue

Remote programming succeed

Lonsdor K518ise adds new ID46 keys to Suzuki Vitara: 1 minute done!

Good News! Lonsdor K518ISE is able to program new ID46 keys to Suzuki Vitara! All done for 1 minute around!

Here is the detail steps:

In Lonsdor K518ise:

Select Immobilization


-> Vitara

-> immobilizer

-> type 1

-> lost all keys programming

In Lonsdor K518ise-1 In Lonsdor K518ise-2

Will start to program a new key

In Lonsdor K518ise-3

Enter the password (generally it’s 0804, 0408)

In Lonsdor K518ise-4

Make sure the input is correct

In Lonsdor K518ise-5

Current key count

In Lonsdor K518ise-6

Insert the key to switch ignition on

In Lonsdor K518ise-7

Dashboard status

In Lonsdor K518ise-8

Lonsdor k518ise is adding a new key

In Lonsdor K518ise-9

Key adding completed!

Add another new key

In Lonsdor K518ise-10

Please insert the key

In Lonsdor K518ise-11

Adding a new key

In Lonsdor K518ise-12

Key adding completed!

In Lonsdor K518ise-13

Lonsdor K518ise Remote Key Programmed for Ford Escape Kuga

Lonsdor K518ISE Key Programmer is an advanced key programmer. It can be works perfectly on Ford Escape Kuga 2015 and just takes a few minutes in whole remote key programmed.

Here you go

Select Add key after Lonsdor K518ISE connected with vehicle.


Insert new key and switch ignition on

Current key count 3


Reading car PIN code, it may need a few times.


Current key count 4

Select Add smart key


Press OK to program key at fist


Reading car PIN code again


Please press remote control unlock button for 1 second within 15 sec.


It works perfectly now!


Lonsdor K518ise Subscribed menus 180 days for free

Good News From Lonsdor, K518ISE series full version 6 months Free. The subscribed menus is extend 180 days free.

Lonsdor K518ise Subscribed menus 180 days for free-00

Menus are divided into two parts: free menus and subscribed menus.
1.Free menus are free for lifetime.
2. Subscribed menus can be used for free for 180 days.
You need to pay for them after the trial period. After the trial period, subscribed menus will not work properly if you don’t pay. And the menus will disappear after updating the device.
A. 365 days is a period and the price is USD600 per period. One year period starts from the day of the trial period finished.
B. Purchase menus with a dealer. You can use the menus normally and permanently after payment.
C. Menus which you purchase includes subscribed menus that have been released and that will have been released in one year period.
D. Subscribed menus beyond one year period requires extra payment.
